10l tara buri m mold inji

Model:KGB70A

KGB70A ne mai cikakken iko 10l tara mashin m moling da aka tsara don kwalban kwalban tsami 15-lita busa. A matsayinka na jagorar kwalin injin ruwa, muna ba da mafita musamman don biyan bukatun abokin ciniki. Mashin ba kawai don kwalabe kawai ba, kwantena na qwarai, da kuma don ƙananan kayan aiki na yau da kullun, amma don samfurori na musamman. Wannan injin din ya sadu da bukatun daban-daban.

Girma: 20lWeight: 7.8t

Aika tambaya

Bayanin Samfura Specification Application

KGB70A 10L tara moling moling inji shine kafaffiyar budewa da rufewa Model, wanda ya yi amfani da sau biyu ja ruwa ya ja da ƙwanƙwasa ƙwanƙwasa ramaki, man Cyferiner kai tsaye matsa lamba kullewa mold, cyfiulator silinder mutu shugaban yi wa'azin. Tsarin tsarin Hydralic Servo, mai saurin amsawa da kuma ceton kuzari.
Mafi kara don wadancan samarwa na samfuri na musamman, na iya sarrafa sifar da kauri mafi dacewa.

Fasali da fa'idodi

Wannan ƙirar itace ƙayyadadden buɗewa da rufewa ninki biyu na rufe fim ɗinku, da kuma silinda man man mai kai tsaye makullin mold
● Canji silima ya mutu jerin
● mafi girman ƙarawa 20l
Ors dace da Ruwa kwalabe, kwantena kwantena, da kuma masu kariya na yau da kullun, da sauransu.
Muhimmin fasalin shi ne cewa tsarin hydraulic ne ke sarrafawa don samun amsa na sauri da ingancin makamashi.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
