183 tebur na filastik

Model:KGS120Z

Sarki Kgs120z shine yankan teburin filastik 183 wanda ke yin na'ura wanda ya dace don aikace-aikacen zagaye na aikace-aikace. Daidai ya cika tebur na filastik ko filastik na filastik mai lalacewa, yana ba da zane-zane na musamman da kuma ingancin ƙira, yana ba ku baki sosai.

Girma: 1000lWeight: 38t

Aika tambaya

Bayanin Samfura Specification Application

Kgs120z 183 Tebur na filastik na tebur yana ƙirƙirar samfurin samfurin Panel na filastik, irin wannan kamar gidan tebur / Ware da sauransu sadu da waɗannan buƙatun samarwa na musamman na musamman, tare da babban gudu Armaser don adana kudin naúrar.
Ya hada da Mai Gudanar da Robow 100, Robot Arm, da kasan Hurta tsarin, inganta yawan aiki da inganci.

Fasali da fa'idodi

Amfani da samfuran masana'antu a cikin masana'antu daban-daban. Ko yana da manyan kwantena masu tsauri a masana'antar masu guba, ko akwatunan marufi da samfuran sunadarai na yau da kullun.
Tsarin ciyarwar yana ɗaukar fasahar-baki kuma ana inganta shi bisa ga halayen samarwa na babban iko na mashin moling na moling. Daidai da ƙididdigar kwararar kayan da rarraba albarkatun ƙasa don tabbatar da ƙwaƙwalwar ƙaƙƙarfan kayan aiki, da kuma kawar da ƙarancin ingancin samfurin, da kuma kawar da lahani masu inganci da ba a cika shi ba.

Specifications

serial number	Material HDPE…	Mold closing oil cylinder(single cylinder)
serial number	Material HDPE…	Machine model:KGS120Z
Specifications
1	Max container capacity	1000 L
2	Output(dry Cycle)	300 PC/HR
3	Machine Dimension(L×W×H)	8.3 M ×3.4 M × 6.8 M
4	Machine weight	38 T
Clamping Unit
1	Clamping force	1200 KN
2	Mold platen size(W×H)	1300 MM×1900 MM
3	Platen openingstroke	600 MM-1600 MM
4	Platen moving stroke	700 MM
5	Max mold size(W×H)	1000 MM×2000 MM
6	Mold thickness	630 MM - 830 MM
Power
1	Servooil pump motor power	25 KW
2	Servo pump displacement	200 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	2 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	120 L/min
7	Average energy consumption	110 KW -130 KW
Extruder unit
1	Screw diameter	120 MM
2	Screw L/D ratio	30 L/D
3	Melting capacit for HDPE	350 Kg/hr
4	Number of heating zone	6 ZONE
5	Screw heating power	32.5 KW
6	Screw fanpower	0.6 KW
7	Extruder motor power	90 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	38.8 KW
3	Maxdie-pin diameter	700(800) MM
4	Accumulator capacity	25(30) L
5	(PE)Accumulator weight	18(22) KG
